All Metals & Forge Group is a producer of open die forgings, seamless rolled rings, and contoured rolled rings up to 200″/5080mm outside diameter. Forging shapes include discs, hubs, blocks, shafts (including step shafts or with flanges), sleeves, cylinders, flats, hexes, rounds, plate, and some custom shapes. Forgings can be produced as finished size, finished size rough machined, forged size, forged size rough machined, as forged size, or as forged size with allowance to finish to your finish size print. Seamless rolled rings and contoured rings are produced to save on material, machining costs and transportation costs. Maximum weight capacity 80,000lbs.
To download a printable PDF of our forging capabilities, Click Here
FORGING CAPABILITIES CHART BY SHAPE
Please see the following forging capabilities chart for size capabilities, and the metal alloy chart for our various metal alloys. Materials that we forge include carbon steel, alloy steel, tool steel, special grades, stainless steel (including PH grades), titanium, aluminum, magnesium, copper, nickel, cobalt, high temperature, super alloys and special alloys.
| SHAPE |
SIZE / WEIGHT |
FERROUS ALLOYS |
NICKEL & SPECIAL ALLOYS |
NON-FERROUS ALLOYS |
| CARBON, ALLOY & TOOL |
STAINLESS |
ALUMINUM |
TITANIUM |
| Max. Width |
120″ |
120″ |
27″ |
60″ |
65″ |
| Max. Weight |
80,000# |
80,000# |
20,000# |
15,000# |
15,000# |
| Max. O.D. |
120″ |
120″ |
50″ |
72″ |
52″ |
| Max. Length |
160″ |
160″ |
65″ |
96″ |
65″ |
| Max. Dia. |
160″ |
160″ |
50″ |
80″ |
65″ |
| Max. Weight |
75,000# |
75,000# |
20,000# |
15,000# |
10,000# |
| Max. O.D. |
200″ |
200″ |
84″ |
80″ |
80″ |
| Max. Length |
65″ |
65″ |
40″ |
65″ |
65″ |
| Max. Length |
420″ |
420″ |
180″ |
264″ |
180″ |
| Max. Weight |
80,000# |
80,000# |
20,000# |
10,000# |
10,000# |
FORGING CAPABILITIES CHART BY MATERIAL
*THESE ALLOYS ARE AVAILABLE IN 30,000# MINIMUM MILL MELT.
| *2315 |
*4110 |
4330 |
6150 |
8740 |
HY80 |
| *2340 |
*4115 |
*4335 |
*6170 |
8750 |
*HY100 |
| 2515 |
4120 |
4337 |
*7290 |
*9115 |
D6AC |
| 3140 |
4125 |
4340 |
*8140 |
9260 |
|
| 3145 |
*4127 |
4615 |
*8150 |
*9262 |
| 3150 |
4130 |
4620 |
*8160 |
9310 |
| 3310 |
4135 |
4630 |
8615 |
9315 |
| 3312 |
4140 |
4640 |
8617 |
9317 |
| 3316 |
4142 |
4720 |
8620 |
94B30 |
| *4015 |
4145
|
5120 |
8630 |
9840 |
| 4017 |
4150 |
5150 |
8640 |
9850 |
| *4020 |
*4155 |
52100 |
8642 |
*F-5 (CR-1/2 MO) |
| 4023 |
*4160 |
6120 |
8645 |
*F-11 (1 1/4 CR-1/2 MO) |
| 4037 |
*4215 |
6140 |
8720 |
*F-22 (2 1/4 CR-1 MO) |
| *4085 |
4320 |
6145 |
8735 |
*F-91 |
|
|
| *17-22 A |
*17-22 AS |
*17-22 AV |
HP9-4-20 |
Nitralloy 135N |
Nitralloy 135 |
| LF1 LF2 LF3 |
CBS600 |
*MA 15 |
HP9-4-30 |
| 1100 |
5083 |
7049 |
7175 |
|
|
| 2014 |
5086 |
7050 |
7475 |
|
|
| 2024 |
6061 |
7075 |
|
|
|
| 2219 |
6063 |
7079 |
|
|
|
|
| 1005 |
1012 |
1023 |
1035 |
|
|
| 1006 |
1015 |
1025 |
1040 |
|
|
| 1008 |
1018 |
1026 |
1045 |
|
|
| 1010 |
1020 |
1029 |
1050 |
|
|
| |
1022 |
1030 |
1070 |
|
|
|
| A-286® |
Incoloy 800® |
Inconel 718® |
Rodar® |
Nimonic 80® |
| AM-335® |
Incoloy 825® |
Inconel 722® |
L605® |
Nimonic 90® |
| Custom 450® |
Incoloy 832® |
Inconel 725® |
Maraging 250® |
Rene 41® |
| Custom 455® |
Incoloy 890® |
Inconel 738® |
Maraging 300® |
Udimet 500® |
| Ferralium 255® |
Incoloy 832® |
Inconel 750® |
Maraging 350® |
Udimet 700® |
| Hastelloy B2® |
Incoloy 901® |
Inconel 751® |
Monel 400 (reg.)® |
*Vascojet 1000® |
| Hastelloy C® |
Incoloy 925® |
Inconel 800® |
Monel 500 (K)® |
VascoMax 250® |
| Hastelloy C276® |
Inconel 600® |
*Inconel 902® |
Nickel 200® |
VascoMax 350 CVM® |
| Hastelloy N® |
Inconel 601® |
Inconel 903® |
Nickel 201® |
Waspalloy® |
| Hastelloy S® |
Inconel 617® |
Inconel W® |
Nitronic 40® |
Zirconium 32® |
| Hastelloy W® |
Inconel 625® |
Invar 36a® |
Nitronic 50® |
20 CB |
| Hastelloy X® |
Inconel 690® |
Invar 42® |
Nitronic 60® |
Greek Ascoloy Grade |
| Haynes 188® |
Inconel 702® |
Jethete M151® |
N155® |
|
| Haynes 230® |
Inconel 706® |
Jethete M152® |
Multimet® |
|
| Haynes 25® |
Inconel 713C® |
Kovar A® |
Nimonic 75® |
|
|
|
All Trademarks and Registered Trademarks (®) are the property of their respective owners. |
| 254 SMO |
314 |
347 |
416 |
440C |
|
| 2205 Super Duplex |
316L |
348 |
418 |
442 |
| *300 Series |
317L |
*400 Series |
420 |
446 |
| 302 |
321 |
403 |
422 |
*500 Series |
| 303 |
322 |
405 |
429 |
501 |
| 304 & 304L |
329 |
409 |
430F |
502 |
| 309 |
330 |
410 |
431 |
333 |
|
| 310 |
333 |
414 |
440A |
|
|
|
| Commercially Pure |
6AL-2SN -4ZR-2MO |
*7AL-4MO |
*CP Grade 1 |
*CP Grade 7 |
| 4AL-3MO-1V |
6AL-2SN -4ZR-6MO |
8AL-1MO-1V |
CP Grade 2 |
*CP Grade 11 |
| *4AL-4MN |
6AL-4V |
13.5V -11CR-3AL |
*CP Grade 3 |
CP Grade 12 |
| 5AL-2.5SN |
6A1-6V-2SN |
Ti17 |
CP Grade 4 |
|
|
| A2 |
D5 |
H21 |
S1 |
W2 |
| A6 |
D6 |
H26 |
S5 |
|
| A10 |
H11 |
H43 |
S7 |
|
| A10 |
H12 |
M2 |
T1 |
|
| D3 |
H13 |
P20 |
W1 |
|
|
